Model No: GR866100281

Gram MARINE COMPACT F610RH60HZLM5M Freezer

Efficient Upright Upright Solid Door, 2/1 Gastronorm Stainless Steel Exterior, Grey ABS Interior

Gram Marine freezers compact range F610 Uprights with 2/1 GN internal sizing. The most efficient compact solution for offshore applications requiring exceptional performance with a reduced footprint.


Gram hydrocarbon gas freezers are quiet running with a cool exterior and minimal heat output for a more comfortable work environment.

Gram sleek and sophisticated Denmark design and engineering is a testament to the modern application of technology in commercial equipment.

Winning Features

  • Commercial upright freezer
  • 70cm(w) x 87cm(d) x 201cm(h)
  • Energy Efficient
  • Sturdy stainless steel marine shelves with tilt prevention
  • Extra sturdy marine legs with adjustable fixed feet
  • Incredible temperature stability, maintain correct and uniform temp throughout
  • Digital temperature control and display
  • Temperature range -25°C/-5°C
  • Right hand hinged reversible door with dedicated positive locking handle
  • Internal LED Lighting Powerful cooling and unique ventilated air distribution system
  • Automatic defrost with evaporation system for defrosted water
  • Cool exterior, minimal heat emission from the cabinet to the room
  • Temp alarms and emergency programs for increased peace of mind
  • Gross volume per cabinet 583L
  • Functional design and easy to clean and maintain

3 year parts and labour warranty, backed by a 10 year spare parts guarantee

Model Variations

  • Marine 610's available with 230V/50 Hz compressor (230V/60 as standard)
  • Available as a standard freezer or refrigerator in white or stainless finish

World leaders in commercial refrigeration efficiency and engineering, Skanos are proud to bring Gram to Australian shores.

(GR866100281)

Product Name COMPACT F 610 RH 60 HZ LM 5M
Volume Gross 583 ltr./20.7 cu.ft.
Exterior/Interior Finish Stainless/ABS lining in grey
External Dimensions W x D x H 695 x 868 x 2005 mm
Equipped with Right hand hinged reversible door with lock, 5 stainless marine shleves, marine legs (not factory fitted)
Refrigerant/GWP R 404 A/0.22 kg/CO2e 862,84 kg/3.922
Electrical Connection 230 V, 60 Hz
Connection Load 571 Watt
Temparature range -25/-5°C
Options 230V/50 Hz also available
Shipping Weight 121.0000kg
Shipping Width 0.900m
Shipping Height 2.150m
Shipping Length 0.740m
Shipping Cubic 1.431900000m3
